| [Vehicle technical parameters] |
| Product trademark |
Cheng Li card |
Announcement batch |
367 |
| product name |
dumper |
product model |
CL3180ZX6AZT |
| gross mass (Kg) |
18000 |
Tank volume (m3) |
|
| Rated load mass (Kg) |
9205 |
Overall dimensions (mm) |
6150×2350×2800 |
| Preparation mass (Kg) |
7850 |
Goods Chamber Size (mm) |
3600×2200×500 |
| Number of passengers (person) |
2,3 |
Maximum saddle load mass (Kg) |
|
| axle weight (Kg) |
6500/11500 |
Top vehicle speed (Km/h) |
89 |
| remarks |
1. Side and rear protective materials are Q235, connection mode: side protection is bolted, rear protection is welded connection, rear protective section size is 120mm 60mm, the lower edge is 490mm above ground height; 2. ABS system manufacturer: Guangzhou Automotive Electronics Co., LTD., ABS model CM4XL-4S / 4M; 3. The vehicle is equipped with driving recorder with satellite positioning function; 4. Select the cab front panel style, front lamp and front lower bumper, and select the side and rear structure of the cargo box.5. Corresponding relationship of engine / fuel consumption declaration (L / 100km): YCS06270-60 / 28.15, YCS06245-60 / 28.15, YCS04200-68 / 28.01.; 6. Equipped with direct power supply ETC; 7. The unloading mode is adopted. Select the installation position of fuel tank, urea tank, battery, air storage cylinder with the chassis, and select the post-processing position and style. |
| [Chassis technical parameters] |
| Chassis model |
CL1181LDJ6 |
Chassis name |
truck chassis |
| brand name |
Cheng Li card |
manufacturing enterprise |
Cheng Li Automobile Group Co., LTD |
| number of axles |
2 |
Number of tires |
6 |
| wheel base (mm) |
3400,3600,3800,3950,4100,4500 |
| tyre size |
10.00R20 18PR,11.00R20 18PR |
| Number of steel plate spring sheets |
8/10+8,9/10+8,9/11+8,6/6+5,8/9+5,8/9+7,8/10+7,3/4+3,9/12+10,7/9+6,11/11+10 |
front gauge (mm) |
1840,1880,1900,1940,1960,1980 |
| Fuel types |
diesel oil |
rear track (mm) |
1750,1800,1860,1880 |
| Emission basis standard |
The GB17691-2018 countries |
| engine type |
Engine production enterprise |
displacement (ml) |
power (Kw) |
YCS04200-68
YCS06245-60
YCS06270-60 |
Guangxi Yuchai Machinery Co., LTD
Guangxi Yuchai Machinery Co., LTD
Guangxi Yuchai Machinery Co., LTD |
4156
6234
6234 |
147
180
199 |
